Datalogic DS6400

READING FEATURES
109
9
DS6400-100-0XX - Resolution: 0.38 mm/15 mils
The diagram shows a global reading area, which includes all possible focus positions, and
the reading area obtained for the DS6400-100-0XX operating with focus position = 140 cm
and barcode density of 0.38 mm (15 mils).
It is possible to obtain the minimum and maximum distance values by referring to the radial
distance curves displayed in Figure 122.
8
4
12
(in)
0
16
28
(in)
20
24
32
36
0
40
50
60
70
80
90
100
110
(cm)
50
40
30
20
0
(cm)
10
-10
0
-20
-30
-40
16
20
-16
-20
-12
-8
-4
120
130
44
40
48
52
-50
-24
60
24
140
150
60
56
Global Reading
Area
-60
Focus
Position = 140 cm
160
64
170
180
68
72
70
28
-70
-28
Figure 121 – Standard Model 0.38 mm / 15 mils Reading Diagram
Note: (0,0) is the center of the laser beam output window.
CONDITIONS
Code = Interleaved 2/5 or Code 39
PCS = 0.90
Pitch angle = 0°
Skew angle = 10° - 20°
Tilt angle = 0°
