Figure F – Connector Panel for DeviceNet Models
Main/Aux. Interface 26-pin D-Sub male connector
1
DeviceNet 5-pin male connector
2
Lonworks 9-pin female connector
3
Figure G – Connector Panel for Profibus Models
Main/Aux. Interface 26-pin D-Sub male connector
1
Profibus 9-pin female connector (white)
2
Lonworks 9-pin female connector
3
