Datalogic DS6400

READING FEATURES
115
9
DS6400-105-0XX - Resolution: 0.25 mm/10 mils
The diagram shows a global reading area, which includes all possible focus positions, and
the reading area obtained for the DS6400-105-0XX operating with focus position = 95 cm
and barcode density of 0.25 mm (10 mils).
It is possible to obtain the minimum and maximum distance values by referring to the radial
distance curves displayed in Figure 128.
8
4
12
(in)
0
12
24
(in)
16
20
28
32
0
30
40
50
60
70
80
90
100
(cm)
50
40
30
20
0
(cm)
10
-10
0
-20
-30
-40
16
20
-16
-20
-12
-8
-4
110
120
40
36
44
48
-50
-24
60
24
130
140
56
52
Global Reading
Area
-60
Focus
Position = 95 cm
Figure 127 - Oscillating Mirror Model 0.25 mm / 10 mils Reading Diagram
Note: (0,0) is the center of the laser beam output window.
CONDITIONS
Code = Interleaved 2/5 or Code 39
PCS = 0.90
Pitch angle = 0°
Skew angle = 10° - 20°
Tilt angle = 0°
