The following diagrams give the overall dimensions of the reader standard model, oscillating
mirror model and mounting brackets. They may be used for their installation.
4.33
4.45
110
113
99
3.90
76
30
74
2.99
1.18
2.85
85
16.5
30
3.34
0.65
60
2.36
1.18
mm
inch
Figure 11 - DS6400 Overall Dimensions
==
==
82
3.22
20
0.78
50
1.96
18
0.71 N°2
25
0.98
10
0.4
22
0.86
42
1.65
Ø4.1 N°2
Ø0.16 N°2
4.5 N° 4 SLOTS
0.18 N°4 SLOTS
82
3.22
50
1.96
35
1.37
50
1.96
72
2.83
100
3.93
4
0.15
130
5.12
126
4.96
106°
73.2
2.88
36
1.41
8.5 N°2 SLOTS
0.33 N°2 SLOTS
Ø8.5
Ø0.33
mm
inch
Figure 12 – ST-237 Mounting Bracket Overall Dimensions
