Datalogic DS6400

DS6400 REFERENCE MANUAL
82
8
Parameter
Default Setting
Parameters
Stop Bits
1
Auxiliary Serial Port
Search for CBX BM100 at Device Startup
Enabled (checked)
Data Tx
Enabled (checked)
Heartbeat
Disable
Pass Through
Disabled (unchecked)
Parameters
Baud Rate
115200
Parity
None
Data Bits
8
Stop Bits
1
Digital I/O Setting
Digital Input Lines Setting
Debouncing For Input 1, 3 and 4
5ms
Debouncing For Input 2
500 µs
Input 1 Active Level Overridden by Op. Mode
Active Closed
Input 2 Active Level Overridden by Op. Mode
Active Closed
Input 3 Active Level Overridden by Op. Mode
Active Closed
Input 4 Active Level Overridden by Op. Mode
Active Closed
Output 1
Line State
Normally Open
Activation Event
Complete Read
Alternative Activation Event
Wrong
Deactivation Event
Timeout
Alternative Deactivation Event
None
Deactivation Timeout (ms)
50
Output 2
Line State
Normally Open
Activation Event
No Read
Alternative Activation Event
Partial Read
Deactivation Event
Timeout
Alternative Deactivation Event
None
Deactivation Timeout (ms)
50
Output 3
Line State
Normally Open
Activation Event
None
Alternative Activation Event
None
Deactivation Event
None
Alternative Deactivation Event
None
