Datalogic Gryphon I GBT4400 Quick Reference Guide

Table of Contents
END USER LICENSE AGREEMENT .............................................................i
Software Product Policy ............................................................................iv
Customers under Software Support ..........................................iv
Description .....................................................................................................1
Setting Up the Reader ................................................................................2
Positioning the Base Station .........................................................2
Changing the Base Station Position ................................ 2
Connecting the Base Station ....................................................................4
Securing the DC Power Cord (Optional) ........................ 5
System and Network Layout .........................................................7
Typical Setup with Cradle and Host................................. 7
Using the BC40xx™ Radio Base .....................................................8
Radio Base LEDs ...................................................................... 8
Cleaning ...........................................................................................................9
Charging the Batteries .............................................................................10
Battery Safety ...................................................................................10
Replacing the Batteries ................................................................12
Using the Gryphon™ I GBT4400 ...........................................................14
Linking the Reader ....................................................................................15
Link Datalogic RF Devices to Base................................. 15
Link Scanner to Bluetooth Adapter............................... 15
Power Off ......................................................................................................16
Selecting the Interface Type ..................................................................16
Interface Selection .........................................................................16
Configuring the Interface ................................................. 16
Keyboard Interface.............................................................. 19
Scancode Tables .................................................................. 21
Country Mode....................................................................... 21
Caps Lock State .................................................................... 26
Numlock.................................................................................. 27
Programming ..............................................................................................28
Using Programming Bar Codes .................................................28
Configure Other Settings .............................................................28
Resetting Standard Product Defaults ......................................28
Reading Parameters .................................................................................29
Aiming System ................................................................................29
Good Read Green Spot Duration ..............................................30
Scan Modes .................................................................................................31
Pick Mode ..........................................................................................33
Multiple Labels in a Volume .......................................................33
Technical Specifications ..........................................................................34
LED and Beeper Indications ...................................................................38
Error Codes ..................................................................................................41
Base Station Indications ..........................................................................42
Statement of Agency Compliance ......................................................43

Datalogic Gryphon I GBT4400 Specifications

General

Wavelength	650 nm
Scanner type	2D
Yaw reading angle	-40 - 40 °
Tilt reading angle	0 - 360 °
Light levels (direct sunlight)	0 - 100000 lx
Input voltage	4.5 - 14.0 V
Battery capacity	2100 mAh
Number of reads per charge	60000
Bluetooth	Yes
Dimensions (WxDxH)	71 x 100 x 181 mm
Certification	China RoHS, EU RoHS, IEC 60825 Class 2
Product color	Black
LED indicators	Charging, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	245 g
