Datalogic Gryphon I GBT4400 Quick Reference Guide

LED and Beeper Indications
40 Gryphon™ I GBT4400
Programming Mode - The following indications ONLY occur when the
reader is in Programming Mode.
INDICATION DESCRIPTION LED BEEPER
Label Programming
Mode Entry
A valid programming
label has been
scanned.
LED blinks
co
ntinu-
ously
Reader sounds
four low fre-
quency beeps.
Label Programming
Mode Rejection of
Label
A label has been
rejected.
N/A
Reader sounds
th
ree times at
lowest frequency
and current vol-
ume.
Label Programming
Mode Acceptance of
Partial Label
In cases where multi-
ple labels must be
scanned to program
one feature, this indi-
cation acknowledges
each portion as it is
successfully scanned.
N/A
Reader sounds
one sh
ort beep at
highest frequency
and current vol-
ume.
Label Programming
Mode Acceptance of
Programming
Configuration
option(s) have been
successfully pro-
grammed via labels
and the reader has
exited Programming
Mode.
N/A
Reader sounds
one h
igh fre-
quency beep and
4 low frequency
beeps followed by
reset beeps.
Label Programming
Mode Cancel Item
Entry
Cancel label has been
scanned.
N/A
Reader sounds
tw
o times at low
frequency and
current volume.

Datalogic Gryphon I GBT4400 Specifications

General

Wavelength	650 nm
Scanner type	2D
Yaw reading angle	-40 - 40 °
Tilt reading angle	0 - 360 °
Light levels (direct sunlight)	0 - 100000 lx
Input voltage	4.5 - 14.0 V
Battery capacity	2100 mAh
Number of reads per charge	60000
Bluetooth	Yes
Dimensions (WxDxH)	71 x 100 x 181 mm
Certification	China RoHS, EU RoHS, IEC 60825 Class 2
Product color	Black
LED indicators	Charging, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	245 g
