Datalogic Magellan 2300HS Product Reference Guide

Product Reference Guide E-17
MSI/Plessey
Label ID
4000
("@")
4000
("@")
4F00
("O")
4000
("@")
4000
("@")
4000
("@")
MSI/Plessey
Length Control
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
MSI/Plessey
Maximum
Label Length
16 16 16 16 16 16
MSI/Plessey
Minimum Label
Length
44 44 4 4
MSI/Plessey
Fixed Length 1
77 77 7 7
MSI/Plessey
Fixed Length 2
88 88 8 8
MSI/Plessey
Stitching
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
Standard 2 of
5 Enable
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
Standard 2 of
5 Check Char-
acter Calcula-
tion
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
Standard 2 of
5 Check Char-
acter Trans-
mission
1
(enable
)
1
(enable)
1
(enable)
1
(enable
)
1
(enable)
1
(enable)
1
(enable)
1
(enable)
Standard 2 of
5 AIM ID
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
Standard 2 of
5 Label ID
5300
("S")
5300
("S")
5300
("S")
5300
("S")
5300
("S")
5300
("S")
5300
("S")
5300
("S")
Table E-2
Aux RS-232
Wincor-
Nixdorf
Single
Cable
IBM 17
OEM
USB
USB
Keybd
PC
KBW

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
