Datalogic Magellan 2300HS Product Reference Guide

E-18 Magellan
TM
2200VS and 2300HS
Standard 2 of
5 Length Con-
trol
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
Standard 2 of
5 Maximum
Label Length
50 50 50 50 50 50 50 50
Standard 2 of
5 Minimum
Label Length
66666666
Standard 2 of
5 Fixed Length
1
10 10 10 10 10 10 10 10
Standard 2 of
5 Fixed Length
2
00000000
Standard 2 of
5 Stitching
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
Table E-2
Aux RS-232
Wincor-
Nixdorf
Single
Cable
IBM 17
OEM
USB
USB
Keybd
PC
KBW

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
