8100/8100Ω and 8200/8200Ω Scanner
Scanner and Scanning-Scale Nomenclature
Controls, indicators and other nomenclature are shown in Figure 1-1.
Figure 1-1. Scanning-Scale Nomenclature
All Weighs™
Platter
G
reen LE
D
Wei
g
hin
g
Surface — Lean
O
versize Produce Her
e
Horizontal
Window
Scale Zero
Push Button
Bonnet
Volume/Tone Push Button
Yellow LED
Vertical
Window
