Datalogic MAGELLAN 8200

B-4 Magellan
®
8100/8100Ω and 8200/8200Ω Scanner
IBM Cable Pinout
Scanner and Scale
Connector Hardware
RJ45, 10 Position
Cable Pinout
Table B-3
PIN # FUNCTION DESCRIPTION
1 +5V pullup +5V pullup
2 N/C No Connection
3 N/C No Connection
4 Serial I/O B Serial Data -
5 N/C No Connection
6 Serial I/O A Serial Data +
7 N/C No Connection
8 +5V out +5V out
9 Ground Signal Ground
10 N/C No Connection
