Product Reference Guide A-1
Appendix A
LED/Beeper Indications & Controls
Figure A-1 shows the operator’s controls and indicators. The descriptions
following identify the use or function of each component.
Figure A-1. Scanner and Scale Controls
Controls and Indicators
The control panel consists of two indicator LEDs and two push buttons as
described in the following pages.
Green LED
Yellow LED
Scale Zero
Push Button
Volume/Tone
Push Button
