Product Reference Guide B-7
EAS Interlock Connector
Scanner and Scale
Connector Hardware
RJ-4
Cable Pinout
NOTE
Antenna Connections. Connect ONLY using approved cables approved by
the manufacturer for this product.
Table B-6
PIN # SIGNAL
1GND
2+5V Out
3EAS Out
4
Speaker Out
a
a.The “Speaker Out” line is an analog signal (5Vpp
max), connected to one of the internal speaker termi-
nals, intended to connect to an external amplifier to
drive an external speaker.
