Datalogic MAGELLAN 8200

B-8 Magellan
®
8100/8100Ω and 8200/8200Ω Scanner
Power Cable
Connector Hardware
6 pin Molex
Cable Pinout
Remote Display
Connector Hardware
4 pin SDL
Cable Pinout
Table B-7
PIN # FUNCTION DESCRIPTION
1 EARTH GND Earth Ground
2 SIGNAL GND Signal Ground
3 +5V IN +5V in
4 N/C No Connection
5 N/C No Connection
6 +12V IN +12V in
Table B-8
PIN # FUNCTION DESCRIPTION
1 +12V OUT +12V out
2 LINE_A_DSPLY LINE A Display
3 LINE_B_DSPLY LINE B Display
4 GND Ground
