MATRIX 210™ PARAMETERS LIST
29
4
USB CONNECTOR MODELS
PARAMETER TYPE SEL STRING DATA
MAIN PORT
Data TX 1 1 ESC B A 0 = Disabled
1 = Enabled
Baud Rate 1 1 ESC B E 0 = 115200
1 = 230400
2 = 460800
3 = 921600
Parity 1 1 ESC B G 0 = None
1 = Odd
2 = Even
Data Bits 1 1 ESC B H 0 = 7
1 = 8
Stop Bits 1 1 ESC B I 0 = 1
1 = 2
Communication
Handshake
1 1 ESC B J 0 = None
1 = XON/XOFF
2 = RTS/CTS
Header String 2 ESC B K Length: 0 to 128
Terminator String 2 ESC B L Length: 0 to 128
Reading Phase ON
String
2 ESC B M Length: 1 to 128
Acquisition Trigger
String
2 ESC B N Length: 1 to 128
Reading Phase OFF
String
2 ESC B O Length: 1 to 128
