Datalogic Matrix 210 Programming Manual

MATRIX 210™ PARAMETERS LIST
31
4
PARAMETER TYPE SEL STRING DATA
WEB SENTINEL SOCKET
Status 1 1 ESC E $ 0 = Disabled
1 = Enabled
Port 0 ESC E % Range: 0 to 65535
IMAGE FTP CLIENT
Status 1 1 ESC E a 0 = Disabled
1 = Enabled on Successful Decoding
2 = Enabled on Decoding Failure
3 = Always Enabled
Image Subsampling 1 1 ESC E b 0 = 1/1
1 = 1/4
2 = 1/16
3 = 1/64
Image Format 1 1 ESC E c 0 = BMP
1 = JPEG
2 = TIFF
JPG Quality (1-100) 0 ESC E d Range: 0 to 100
FTP Server Address 2 ESC E e Length: 0 to 256
User Name 2 ESC E f Length: 0 to 256
Password 2 ESC E g Length: 0 to 256
Image Saving Path 2 ESC E h Length: 0 to 256
Image File Name 2 ESC E i Length: 0 to 256
Max Different Files To Save 0 ESC E j Range: 0 to 1000000
File Type 1 1 ESC E k 0 = ASCII
1 = Binary
ETHERNET/IP
Status 1 1 ESC E w 0 = Disabled
1 = Enabled
Header String 2 ESC E x Length: 0 to 128
Terminator String 2 ESC E y Length: 0 to 128
Keep Read Item 1 1 ESC e z 0 = Keep Always
1 = Discard After Read
HTTP SERVER
Status 1 1 ESC E 1 0 = Disabled
1 = Enabled
MODBUS TCP
Status 1 1 ESC M P 0 = Disabled
1 = Enabled
Header String 2 ESC M Q Length: 0 to 128
Terminator String 2 ESC M R Length: 0 to 128
Start Register 0 ESC M S Range: 0 to 256
Number Of Registers 0 ESC M T Range: 0 to 256 (valid when Type =
Client)
Type 1 1 ESC M V 0 = Server
1 = Client
Server Address 2 ESC M U Length: 0 to 256
Number Of Registers 0 ESC M Z Range: 0 to 256 (valid when Type =
Server)
GET IP CLIENT
Product Name 2 ESC F J Length: 0 to 15
