HOST MODE PROGRAMMING
32
4
25 PIN CONNECTOR MODELS + CBX ETHERNET TCP/IP MODULE
ETHERNET MODELS + CBX ETHERNET TCP/IP MODULE
PARAMETER TYPE SEL STRING DATA
CBX ETHERNET SYSTEM
Status 1 1 ESC q A 0 = Disabled
1 = Enabled
DHCP Client 1 1 ESC q C 0 = Disabled
1 = Enabled
IP Address 2 ESC q D Length: 0 to 15
Subnet Mask 2 ESC q E Length: 0 to 15
Gateway Address 2 ESC q F Length: 0 to 15
CBX ETHERNET DATA SOCKET
Status 1 1 ESC q I 0 = Disabled
1 = Enabled
Header String 2 ESC q J Length: 0 to 128
Terminator String 2 ESC q K Length: 0 to 128
Protocol 1 1 ESC q L 0 = TCP
1 = UDP
Port 0 ESC q M Range: 0 to 65535
Socket Type 1 1 ESC q N 0 = Server
1 = Client
Server Address 2 ESC q O Length: 0 to 256
Reading Phase ON String 2 ESC q P Length: 1 to 128
Acquisition String 2 ESC q Q Length: 1 to 128
Reading Phase OFF
String
2 ESC q R Length: 1 to 128
CBX ETHERNET IMAGE SOCKET
Status 1 1 ESC q S 0 = Disabled
1 = Enabled on Successful Decoding
2 = Enabled on Decoding Failure
3 = Always Enabled
Image Subsampling 1 1 ESC q T 0 = 1/1
1 = 1/4
2 = 1/16
3 = 1/64
Image Format 1 1 ESC q U 0 = BMP
1 = JPEG
2 = TIFF
JPG Quality (1-100) 0 ESC q V Range: 0 to 100
Protocol 1 1 ESC q W 0 = TCP
1 = UDP
Port 0 ESC q X Range: 0 to 65535
Type 1 1 ESC q Y 0 = Server
1 = Client
Server Address 2 ESC q Z Length: 0 to 256
