Datalogic Matrix 210 Programming Manual

MATRIX 210™ PARAMETERS LIST
33
4
PARAMETER TYPE SEL STRING DATA
CBX ETHERNET IMAGE FTP CLIENT
Status 1 1 ESC q a 0 = Disabled
1 = Enabled on Successful Decoding
2 = Enabled on Decoding Failure
3 = Always Enabled
Image Subsampling 1 1 ESC q b 0 = 1/1
1 = 1/4
2 = 1/16
3 = 1/64
Image Format 1 1 ESC q c 0 = BMP
1 = JPEG
2 = TIFF
JPG Quality (1-100) 0 ESC q d Range: 0 to 100
FTP Server Address 2 ESC q e Length: 0 to 256
User Name 2 ESC q f Length: 0 to 256
Password 2 ESC q g Length: 0 to 256
Image Saving Path 2 ESC q h Length: 0 to 256
Image File Name 2 ESC q i Length: 0 to 256
Max Different Files To
Save
0 ESC q j Range: 0 to 1000000
File Type 1 1 ESC q k 0 = ASCII
1 = Binary
CBX ETHERNET MODBUS TCP
Status 1 1 ESC M F 0 = Disabled
1 = Enabled
Header String 2 ESC M G Length: 0 to 128
Terminator String 2 ESC M H Length: 0 to 128
Start Register 0 ESC M I Range: 0 to 256
Number Of Registers 0 ESC M J Range: 0 to 256 (valid when Type =
Client)
Type 1 1 ESC M L 0 = Server
1 = Client
Server Address 2 ESC M K Length: 0 to 256
Number Of Registers 0 ESC M = Range: 0 to 256 (valid when Type =
Server)
CBX ETHERNET/IP
Status 1 1 ESC q w 0 = Disabled
1 = Enabled
Header String 2 ESC q x Length: 0 to 128
Terminator String 2 ESC q y Length: 0 to 128
Keep Read Item 1 1 ESC q z 0 = Keep Always
1 = Discard After Read
CBX ETHERNET GET IP CLIENT
Product Name 2 ESC F X Length: 0 to 15
CBX ETHERNET WEB SENTINEL SOCKET
Status 1 1 ESC q $ 0 = Disabled
1 = Enabled
Port 0 ESC q % Range: 0 to 65535
