MATRIX 210™ PARAMETERS LIST
47
4
PARAMETER TYPE SEL STRING DATA
53 = MSI
54 = Code 32
55 = Locator Edge
Minimum Number of
Characters #n
0 ESC r #n Range: 1 to 1042
Maximum Number of
Characters #n
0 ESC s #n Range: 1 to 1042
Code Position Frame:
Top #n
0 ESC N #n Range: 0 to 2048
Code Position Frame:
Bottom #n
0 ESC O #n Range: 0 to 2048
Code Position Frame:
Left #n
0 ESC L #n Range: 0 to 2048
Code Position Frame:
Right #n
0 ESC M #n Range: 0 to 2048
Code Quality Index #n 1 1 ESC P #n 0 = ISO-IEC / AIM DPM Overall Grade
1 = ISO-IEC Symbol Contrast
2 = ISO-IEC Print Growth
3 = ISO-IEC / AIM DPM Axial Non-
Uniformity
4 = ISO-IEC / AIM DPM Unused ECC
5 = ISO-IEC / AIM DPM Decode
6 = ISO-IEC Modulation
7 = ISO-IEC Mean Edge Contrast
8 = ISO-IEC Decodability
9 = ISO-IEC / AIM DPM Fixed Pattern
Damage
10 = ISO-IEC / AIM DPM Grid Non-
Uniformity
11 = ISO-IEC / AIM DPM Minimum
Reflectance
12 = ISO-IEC Defects
13 = AIM DPM Cell Contrast
14 = AIM DPM Cell Modulation
15 = AS9132 Dot Size/Cell Fill
16 = AS9132 Dot Center Offset
17 = AS9132 Dot Ovality
18 = AS9132 Quiet Zone
19 = AS9132 Symbol Contrast
20 = AS9132 Angle Of Distortion
21 = None
ISO-IEC 16022-18004
Threshold
1 1 ESC Q #n 0 = Any Grade
1 = Grade A
2 = Grade B
3 = Grade C
4 = Grade D
ISO-IEC 15415
Threshold
1 1 ESC R #n 0 = Any Grade
1 = Grade A
2 = Grade B
3 = Grade C
4 = Grade D
ISO-IEC 15416
Threshold
1 1 ESC S #n 0 = Any Grade
1 = Grade A
2 = Grade B
3 = Grade C
4 = Grade D
