HOST MODE PROGRAMMING
48
4
PARAMETER TYPE SEL STRING DATA
AIM DPM Threshold 1 1 ESC T #n 0 = Any Grade
1 = Grade A
2 = Grade B
3 = Grade C
4 = Grade D
Match Code #n 2 ESC w #n Length: 1 to 1042
Wildcard
Character #n
2 ESC u #n Length: 1
Placeholder Character
#n
2 ESC v #n Length: 1
Local No-Read
Message #n
2 ESC t #n Length: 0 to 64
Local Multiple Read
Message #n
2 ESC > #n Length: 0 to 64
NOTE
Special characters <FE
H
> and <FD
H
> must be added after #n in the
programming string to indicate parameter Depth > 9. Refer to paragraph 3.2
for further details.
PARAMETER TYPE SEL STRING DATA
DATA FORMAT
Code Field Justification 1 1 ESC K A 0 = Disabled
1 = Left
2 = Right
Code Field Length 0 ESC K B Range: 1 to 1.042
Fill Character 2 ESC K C Length: 1
Code Field Cutting 1 1 ESC K D 0 = None
1 = Beginning
2 = Middle
3 = End
Separator String 2 ESC K E Length: 1 to 32
(Global) No Read
message
2 ESC K F Length: 0 to 64
(Global) Multiple Read
message
2 ESC J E Length: 0 to 64
Phase-Overrun
Message
2 ESC K I Length: 0 to 16
Data Packet Separator
string
2 ESC K G Length: 0 to 32
Data Packet Format
(%1, %2, ... are special
characters)
2 ESC K J Length: 0 to 128
%1 = Code Identifier
%2 = Code Data
%3 = Code Center (X-axis)
%4 = Code Center (Y-axis)
%5 = Code Orientation
%6 = Code Quality Index (%)
%8 = Image Lighting Quality (%)
%A = Code Producer ID (Master RS232
or Master Synchronized)
%M = Code Data Length
%N = Decode Time (ms)
%O = Reading Phase Counter
%P = Acquisition Counter
