MATRIX 210™ PARAMETERS LIST
55
4
PARAMETER TYPE SEL STRING DATA
Phase-Overrun
Message
2 ESC K I Length: 0 to 16
Data Packet Separator
string
2 ESC K G Length: 0 to 32
Data Packet Format
(%1, %2, ... are special
characters)
2 ESC K J Length: 0 to 128
%1 = Code Identifier
%2 = Code Data
%3 = Code Center (X-axis)
%4 = Code Center (Y-axis)
%5 = Code Orientation
%6 = Code Quality Index (%)
%8 = Image Lighting Quality (%)
%A = Code Producer ID
%M = Code Data Length
%N = Decode Time (ms)
%O = Reading Phase Counter
%P = Acquisition Counter
%_ = Global Diagnostic Status
%C = ISO-IEC / AIM DPM Overall (grade)
%D = ISO-IEC / AIM DPM Overall (value)
%E = ISO-IEC Symbol Contrast / AIM
DPM Cell Contrast (grade)
%F = ISO-IEC Symbol Contrast AIM
DPM Cell Contrast (value)
%G = ISO-IEC Print Growth (grade)
%H = ISO-IEC Print Growth (value)
%I = ISO-IEC / AIM DPM Axial Non-
Uniformity (grade)
%J = ISO-IEC / AIM DPM Axial Non-
Uniformity (value)
%K = ISO-IEC / AIM DPM Unused ECC
(grade)
%L = ISO-IEC / AIM DPM Unused ECC
(value)
%a = ISO-IEC / AIM DPM Decode
(grade)
%Q = ISO-IEC Modulation / AIM DPM
Cell Modulation (grade)
%R = ISO-IEC Modulation / AIM DPM
Cell Modulation (value)
%S = ISO-IEC Mean Edge Contrast
(grade)
%T = ISO-IEC Mean Edge Contrast
(value)
%U = ISO-IEC Decodability (grade)
%V = ISO-IEC Decodability (value)
%m = ISO-IEC / AIM DPM Fixed Pattern
Damage (grade)
%W = ISO-IEC / AIM DPM Fixed Pattern
Damage (value)
%n = ISO-IEC / AIM DPM Grid Non-
Uniformity (grade)
%X = ISO-IEC / AIM DPM Grid Non-
Uniformity (value)
%o = ISO-IEC / AIM DPM Minimum
Reflectance (grade)
%Y = ISO-IEC / AIM DPM Minimum
Reflectance (value)
