HOST MODE PROGRAMMING
56
4
PARAMETER TYPE SEL STRING DATA
%p = ISO-IEC Defects (grade)
%Z = ISO-IEC Defects (value)
%q = AS9132 Dot Size/Cell Fill (grade)
%u = AS9132 Dot Size/Cell Fill (value)
%r = AS9132 Dot Center Offset (grade)
%v = AS9132 Dot Center Offset (value)
%s = AS9132 Dot Ovality (Grade)
%w = AS9132 Dot Ovality (value)
%t = AS9132 Angle Of Distortion (grade)
%y = AS9132 Angle Of Distortion (value)
%z = AS9132 Quiet Zone (grade)
%0 = AS9132 Quiet Zone (value)
%b = AS9132 Symbol Contrast (grade)
%c = AS9132 Symbol Contrast (value)
Statistics Field
Separator String
2 ESC K H Length: 0 to 32
Statistics Field Format
(%1, %2, ... are special
characters)
2 ESC K S Length: 0 to 128
%1 = Phase Overrun Message
%2 = Phase or Acquisition Counter
%3 = No Read Counter
%4 = Partial Read Counter
%5 = Complete Read Counter
%6 = Right Code Counter
(Match Code enabled)
%7 = Wrong Code Counter (Match Code
enabled)
%8 = Multiple Read Counter
Symbology Identifiers 1 1 ESC K K 0 = Disabled
1 = Enabled
SYMBOLOGY IDENTIFIERS
Data Matrix ECC200 2 ESC L A Length: 0 to 32
GS1 Data Matrix 2 ESC L > Length: 0 to 32
QR Code 2 ESC L C Length: 0 to 32
Aztec Code 2 ESC L D Length: 0 to 32
Maxicode 2 ESC L E Length: 0 to 32
PDF417 2 ESC L B Length: 0 to 32
Micro PDF417 2 ESC L y Length: 0 to 32
Interleaved 2 of 5 2 ESC L X Length: 0 to 32
Code 39 2 ESC L V Length: 0 to 32
Code 39 Full ASCII 2 ESC L W Length: 0 to 32
Codabar 2 ESC L v Length: 0 to 32
Code 128 2 ESC L T Length: 0 to 32
GS1-128 (ex EAN 128) 2 ESC L U Length: 0 to 32
Code 93 2 ESC L w Length: 0 to 32
EAN-13 2 ESC L e Length: 0 to 32
EAN-8 2 ESC L f Length: 0 to 32
UPC-A 2 ESC L g Length: 0 to 32
UPC-E 2 ESC L h Length: 0 to 32
EAN-13 AddOn 2 2 ESC L i Length: 0 to 32
EAN-8 AddOn 2 2 ESC L j Length: 0 to 32
UPC-A AddOn 2 2 ESC L k Length: 0 to 32
UPC-E AddOn 2 2 ESC L m Length: 0 to 32
EAN-13 AddOn 5 2 ESC L n Length: 0 to 32
EAN-8 AddOn 5 2 ESC L o Length: 0 to 32
UPC-A AddOn 5 2 ESC L p Length: 0 to 32
