MATRIX 210™ PARAMETERS LIST
57
4
PARAMETER TYPE SEL STRING DATA
UPC-E AddOn 5 2 ESC L q Length: 0 to 32
Australia Post 2 ESC L F Length: 0 to 32
PostNet 2 ESC L G Length: 0 to 32
Planet 2 ESC L H Length: 0 to 32
Japan Post 2 ESC L I Length: 0 to 32
KIX Code 2 ESC L J Length: 0 to 32
Royal Mail 4 State 2 ESC L K Length: 0 to 32
Intelligent Mail 2 ESC L Y Length: 0 to 32
Swedish Postal 2 ESC L ? Length: 0 to 32
GS1 DataBar Expanded 2 ESC L r Length: 0 to 32
GS1 DataBar Expanded
Stacked
2 ESC L x Length: 0 to 32
GS1 DataBar Limited 2 ESC L s Length: 0 to 32
GS1 DataBar 2 ESC L t Length: 0 to 32
GS1 DataBar Stacked 2 ESC L u Length: 0 to 32
Code 128 of Composite 2 ESC L L Length: 0 to 32
GS1 DataBar Expanded
of Composite
2 ESC L M Length: 0 to 32
GS1 DataBar Expanded
Stacked of Composite
2 ESC L z Length: 0 to 32
GS1 DataBar Limited of
Composite
2 ESC L N Length: 0 to 32
GS1 DataBar of
Composite
2 ESC L O Length: 0 to 32
GS1 DataBar Stacked
of Composite
2 ESC L P Length: 0 to 32
CC-A of Composite 2 ESC L Q Length: 0 to 32
CC-B of Composite 2 ESC L R Length: 0 to 32
CC-C of Composite 2 ESC L S Length: 0 to 32
Pharmacode 2 ESC L A Length: 0 to 32
MSI 2 ESC L < Length: 0 to 32
Standard 2 of 5 2 ESC L - Length: 0 to 32
Matrix 2 of 5 2 ESC L [ Length: 0 to 32
Code 32 2 ESC L _ Length: 0 to 32
RESULTS
Partial Read TX 1 1 ESC K L 0 = Disabled
1 = Enabled
Message TX Selection 1 1 ESC K M 0 = On Complete Read
1 = After Reading Phase OFF
2 = Delayed TX Line
Conveyor Speed
(mm/sec)
0 ESC K V Range: 50 to 10000
Delayed TX Line
Distance (mm)
0 ESC K Z Range: 100 to 20000
Physical Encoder 1 1 ESC K W 0 = Disabled
1 = Enabled
Encoder Step
(hundredths of mm)
0 ESC K X Range: 1 to 10000
Output Lines Activation 1 1 ESC K N 0 = On Complete Read
1 = After Reading Phase OFF
STATISTICS
Status 1 1 ESC K O 0 = Disabled
1 = Enabled
Number of Samples 0 ESC K P Range: 5 to 1000
