MATRIX 210™ PARAMETERS LIST
59
4
PARAMETER TYPE SEL STRING DATA
2048 = ISO-IEC / AIM DPM Unused ECC
4096 = ISO-IEC Modulation
8192 = ISO-IEC Mean Edge Contrast
16384 = ISO-IEC Decodability
32576 = ISO-IEC / AIM DPM Fixed
Pattern Damage
65536 = ISO-IEC / AIM DPM Grid Non-
Uniformity
131072 = ISO-IEC / AIM DPM Minimum
Reflectance
262144 = ISO-IEC Defects
524288 = ISO-IEC / AIM DPM Decode
1048576 = AIM DPM Cell Contrast
2097152 = AIM DPM Cell Modulation
4194304 = AS9132 Dot Size/Cell Fill
8388608 = AS9132 Dot Center Offset
16777216 = AS9132 Dot Ovality
33554432 = AS9132 Quiet Zone
67108864 = AS9132 Angle Of Distortion
134217728 = AS9132 Symbol Contrast
268435456 = Multiple Read
Activation Events
(Match Code enabled)
3 28 ESC O C 0 = None
1 = Right Code
2 = Wrong Code
4 = No Read
8 = Acquisition Trigger
16 = Phase ON
32 = Phase OFF
64 = Run Mode
128 = Host Control Mode
256 = ISO-IEC Symbol Contrast
512 = ISO-IEC Print Growth
1024 = ISO-IEC / AIM DPM Axial Non-
Uniformity
2048 = ISO-IEC / AIM DPM Unused ECC
4096 = ISO-IEC Modulation
8192 = ISO-IEC Mean Edge Contrast
16384 = ISO-IEC Decodability
32576 = ISO-IEC / AIM DPM Fixed
Pattern Damage
65536 = ISO-IEC / AIM DPM Grid Non-
Uniformity
131072 = ISO-IEC / AIM DPM Minimum
Reflectance
262144 = ISO-IEC Defects
524288 = ISO-IEC / AIM DPM Decode
1048576 = AIM DPM Cell Contrast
2097152 = AIM DPM Cell Modulation
4194304 = AS9132 Dot Size/Cell Fill
8388608 = AS9132 Dot Center Offset
16777216 = AS9132 Dot Ovality
33554432 = AS9132 Quiet Zone
67108864 = AS9132 Angle Of Distortion
134217728 = AS9132 Symbol Contrast
268435456 = Multiple Read
Additional Activation
Events
3 1 ESC O - 0 = None
1 = External Host Command
