Datalogic Matrix 210 Programming Manual

HOST MODE PROGRAMMING
60
4
PARAMETER TYPE SEL STRING DATA
ISO-IEC 16022-18004
Threshold
1 1 ESC O D 0 = Grade A
1 = Grade B
2 = Grade C
3 = Grade D
ISO-IEC 15415
Threshold
1 1 ESC O b 0 = Grade A
1 = Grade B
2 = Grade C
3 = Grade D
ISO-IEC 15416
Threshold
1 1 ESC O c 0 = Grade A
1 = Grade B
2 = Grade C
3 = Grade D
AIM DPM Threshold 1 1 ESC O i 0 = Grade A
1 = Grade B
2 = Grade C
3 = Grade D
Number Of Events 0 ESC O E Range: 1 to 255
Number of Reading
Phases
0 ESC O F Range: 1 to 255
Deactivation Events 3 4 ESC O G 0 = None
1 = Timeout
2 = Acquisition Trigger
4 = Phase ON
8 = Phase OFF
Deactivation Timeout
(ms)
0 ESC O H Range: 1 to 15000
Activate On Any
Diagnostics Errors
1 1 ESC O l 0 = Disabled
1 = Enabled
Deactivate When All
Errors Recovered
1 1 ESC O m 0 = Disabled
1 = Enabled
Activate On Trend
Analysis
1 1 ESC O n 0 = Disabled
1 = Enabled
Reading Rate
Threshold (%)
0 ESC O p Range: 0 to 100
Blinking Activation
Period (sec)
0 ESC O q Range: 0 to 180
(0 = Disabled)
Deactivate When Trend
Recovered
1 1 ESC O r 0 = Disabled
1 = Enabled
OUTPUT 2
Line Function 1 1 ESC O d 0 = Standard
1 = External Lighting System
2 = External Fieldbus
3 = External Host Command
Line State 1 1 ESC O I 0 = Normally Open
1 = Normally Closed
