USER’S MANUAL
27
LED INDICATORS
The LEDs illuminate to indicate various functions or errors on the reader. The following
tables list these indications. The good read LED indicator is programmable, and may or
may not be enabled ("
Scanner Settings" on page 29 for more details). The Charging LED is
configurable via SDK.
LED Status Description
Charging LED
Red Constant The device is charging.
Green Costant Charging is complete.
Red Blink Charge fault.
White Blink Notifications.
Blue Blink Device in Battery Swap procedure.
Good Read Indicator
Red
Light is solid red from the time the user
pr
esses the scan key until the barcode is
decoded, until the scanner times out, or until
the user releases the scan key.
Green
Light changes to solid green when a good
decode is comple
ted.
Battery Swap LEDs
Red Do not remove the battery.
Green Battery can be replaced.
