Using the Quickscan™ QD2131 Reader
4 QuickScan™ QD2131
Using the Quickscan™ QD2131
Reader
Bar Code Reading
Point the reader at the target and pull the trigger to enable
the illuminator (red beam) to decode the bar code label. The
illuminator will remain on until the trigger is released, or a
label is read, or the "maximum scan on time" is reached.
When scanning a bar code label, you can adjust the distance
or angle to the label to help facilitate reading.
Aim and Scan
012345
012345
65°65°
