Datalogic QuickScan QD2131 Quick Reference Guide

Quick Reference Guide i
Table of Contents
Software Product Policy ............................................................. vi
Description .................................................................................... 1
Setting Up the Reader ................................................................. 2
Connect/Disconnect Cable to Reader ............................... 2
Connect Host Interface ....................................................... 3
Using the Quickscan™ QD2131 Reader ...................................... 4
Bar Code Reading ................................................................ 4
Programming ................................................................................ 5
Using Programming Bar Codes ......................................... 5
Configure Other Settings .................................................... 5
Resetting Product Defaults ............................................... 5
Selecting the Interface Type ....................................................... 6
Interface Selection .............................................................. 6
Configuring the Interface .......................................... 6
Keyboard Interface .................................................... 8
Scancode Tables......................................................... 9
Country Mode........................................................... 10
Caps Lock State........................................................ 14
Numlock.................................................................... 15
Reading Parameters ..................................................................15
Good Read Green Spot Duration .....................................16
Operating Modes ........................................................................17
Scan Mode .........................................................................17
Technical Specifications ............................................................19
LED and Beeper Indications ......................................................22
Error Codes .................................................................................24
Datalogic Limited Factory Warranty ...............................25
Ergonomic Recommendations .................................................27
Cleaning .......................................................................................28
Support Through the Website ..................................................29

Datalogic QuickScan QD2131 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Scanner type	1D
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional
2D (matrix & stacked) barcodes supported	Not supported
Product color	Black
International Protection (IP) code	IP41
Input voltage	4.75 - 14 V
Power consumption	140 mA
Power source type	Battery
Standard interfaces	USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	91 mm
Width	163 mm
Height	41 mm
Weight	150 g
