Datalogic QuickScan QD2131 Quick Reference Guide

Error Codes
24 QuickScan™ QD2131
Error Codes
Upon startup, if the reader sounds a long tone, this means the
reader has not passed its automatic Selftest and has entered
FRU (Field Replaceable Unit) isolation mode. If the reader is
reset, the sequence will be repeated. Press and release the
trigger to hear the FRU indication code.
The following table describes the LED flashes/beep codes
associated with an error found.
Label Pro-
gramming
Mode Accep-
tance of Pro-
gramming
Configuration
option(s) have been
successfully pro-
grammed via labels
and the reader has
exited Program-
ming Mode.
N/A
Reader sounds
one high fre-
quency beep
and 4 low fre-
quency beeps
followed by
reset beeps.
Label Pro-
gramming
Mode Cancel
Item Entry
Cancel label has
been scanned.
N/A
Reader sounds
two times at
low frequency
and current
volume.
Number of
LED Flashes/
Beeps
Error
Corrective
Action
1 Configuration
Contact Helpdesk
for assistance
2 Interface PCB
6 Digital PCB
11 Imager

Datalogic QuickScan QD2131 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Scanner type	1D
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional
2D (matrix & stacked) barcodes supported	Not supported
Product color	Black
International Protection (IP) code	IP41
Input voltage	4.75 - 14 V
Power consumption	140 mA
Power source type	Battery
Standard interfaces	USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	91 mm
Width	163 mm
Height	41 mm
Weight	150 g
