Datalogic QuickScan QD2131 Quick Reference Guide

Technical Specifications
Quick Reference Guide 19
Technical Specifications
The following table contains Physical and Performance Char-
acteristics, User Environment and Regulatory information.
Item Description
Physical Characteristics
Color Black & white
Dimensions
Height 6.4"/163 mm
Length 3.6"/91 mm
Width 1.6"/41 mm
Weight (without
cable)
Approximately 5.3 ounces/150 g
Electrical Characteristics
Voltage & Current
a
a. Typical input current measured @5V under factory default configuration.
Input Voltage: 4.5 - 14.0VDC
Operating (typical): 140mA
Operating (max): 380mA
Idle/standby (typical): 50mA
Performance Characteristics
Light Source LEDs
Roll (Tilt) Tolerance
b
b. Based on ISO 15423 specifications.
Up to ± 45°
Pitch Tolerance
b
± 65°
Skew (Yaw) Toler-
ance
b
± 70°
Field of View 56 ± 2°
Print Contrast Mini-
mum
25% minimum reflectance

Datalogic QuickScan QD2131 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Scanner type	1D
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional
2D (matrix & stacked) barcodes supported	Not supported
Product color	Black
International Protection (IP) code	IP41
Input voltage	4.75 - 14 V
Power consumption	140 mA
Power source type	Battery
Standard interfaces	USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	91 mm
Width	163 mm
Height	41 mm
Weight	150 g
