Datalogic QuickScan QD2131 Quick Reference Guide

Technical Specifications
20 QuickScan™ QD2131
Depth of Field (Guaranteed)
a
a. 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade
A, typical environmental light, 20°C, label inclination 10°
Symbology
Code 39
5mil: 0.8" - 7" (2 - 18cm)
7.5mils: 0.8"- 12" (2 - 30cm)
10mil: 0.8" - 17" (2 - 44cm)
20mil: up to 29.5" (75cm)
EAN 13mil: 0.8" - 23" (2 - 58cm)
Minimum
Element Width
Max Resolution = 4 mil
Decode Capability
1D Bar Codes
UPC/EAN/JAN (A, E, 13, 8); UPC/EAN/JAN (including P2 /P5);
UPC/EAN/JAN (including; ISBN / Bookland & ISSN); UPC/EAN
Coupons; Code 39 (including full ASCII); Code 39 Trioptic; Code39
CIP (French Pharmaceutical); LOGMARS (Code 39 w/ standard
check digit enabled); Code 32 (Italian Pharmacode 39); Code 128;
Code 128 ISBT; Interleaved 2 of 5; Standard 2 of 5; Interleaved 2 of
5 CIP (HR); Industrial 2 of 5; IATA 2 of 5 Air cargo code; Datalogic 2
of 5, Code 4, Code 5, Follet 2 of 5, BC412, Code 11; Codabar; Cod-
abar (NW7); ABC Codabar; EAN 128; Code 93 ; MSI; PZN; Plessey;
Anker Plessey; GS1 DataBar Omnidirectional; GS1 DataBar Lim-
ited; GS1 DataBar Expanded; GS1 DataBar Truncated; DATABAR
Expanded Coupon.
Interfaces Supported
RS-232, Keyboard Wedge, USB Com Std.,
USB Keyboard, USB OEM
User Environment
Operating Tempera-
ture
0° to 50° C (32° to 122° F)
Storage Temperature -40° to 70 °C (-40° to 158° F)

Datalogic QuickScan QD2131 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Scanner type	1D
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional
2D (matrix & stacked) barcodes supported	Not supported
Product color	Black
International Protection (IP) code	IP41
Input voltage	4.75 - 14 V
Power consumption	140 mA
Power source type	Battery
Standard interfaces	USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	91 mm
Width	163 mm
Height	41 mm
Weight	150 g
