Datalogic QuickScan QD2131 Quick Reference Guide

Technical Specifications
Quick Reference Guide 21
Humidity
Operating: 0% to 95% relative humidity,
non-condensing
Drop Specifications
Scanner withstands 18 drops from 1.5
meters (5.0 feet) to concrete
Ambient Light
Immunity
Up to 120,000 Lux
Contaminants
Spray/rain Dust/
particulates
IEC 529-IP42

Datalogic QuickScan QD2131 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Scanner type	1D
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional
2D (matrix & stacked) barcodes supported	Not supported
Product color	Black
International Protection (IP) code	IP41
Input voltage	4.75 - 14 V
Power consumption	140 mA
Power source type	Battery
Standard interfaces	USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	91 mm
Width	163 mm
Height	41 mm
Weight	150 g
