Datalogic QuickScan QD2131 Quick Reference Guide

LED and Beeper Indications
Quick Reference Guide 23
Programming Mode - The following indications ONLY occur
when the reader is in Programming Mode
.
Reader
Disabled
The reader has
been disabled by
the host.
The LED blinks
continuously
N/A
Green Spot
a
flashes
momentarily
Upon success-
ful read of a
label, the soft-
ware shall turn
the green spot
on for the time
specified by the
configured
value.
N/A N/A
a
Except when in sleep mode or when a Good Read LED Duration other than
00 is selected
INDICATION DESCRIPTION LED BEEPER
Label Pro-
gramming
Mode Entry
A valid program-
ming label has
been scanned.
LED blinks
continuously
Reader sounds
four low fre-
quency beeps.
Label Pro-
gramming
Mode Rejec-
tion of Label
A label has been
rejected.
N/A
Reader sounds
three times at
lowest fre-
quency and
current vol-
ume.
Label Pro-
gramming
Mode Accep-
tance of Par-
tial Label
In cases where
multiple labels
must be scanned
to program one
feature, this indica-
tion acknowledges
each portion as it is
successfully
scanned.
N/A
Reader sounds
one short beep
at highest fre-
quency and
current vol-
ume.
Indicator Description LED Beeper

Datalogic QuickScan QD2131 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Scanner type	1D
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional
2D (matrix & stacked) barcodes supported	Not supported
Product color	Black
International Protection (IP) code	IP41
Input voltage	4.75 - 14 V
Power consumption	140 mA
Power source type	Battery
Standard interfaces	USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	91 mm
Width	163 mm
Height	41 mm
Weight	150 g
