15.20 (SG-BWS) SAFETY CONTROL UNITS
Type 4 safety control unit
Type 4 safety control unit 4 - 8 single beam devices
Type 4 control unit with double Muting
Type 4 control unit with double Muting for up to 8 photocells
SG-BWS-T4 safety system consists of a control unit enclosed in a plastic housing to be installed on OMEGA/DIN
rail equipped with 16 screw clamps that can be connected up to 4 sets of photocells of the S5-ST, SL5-ST, S300
series.
Fig 125 - SG-BWS-T4 Safety control unit
SG-BWS-T4-MT safety system consists of a control unit enclosed in a plastic housing, to be installed on
OMEGA/DIN rail, equipped with 48 screw clamps that can be connected up to 4 sets of photocells of the S5-ST,
SL5-ST, S300 series and to up to 2 safety light curtains.
Fig 126 - SG-BWS-T4-MT Safety control unit
