15.15 SINGLE MUTING ARMS
Single active arm with RRX sensors V2
Single passive arm with reflectors V2
The SG4 EXTENDED and SG2 MUTING series light curtains can be equipped with retro-reflective Muting arms to
obtain the “T” or “L” configuration.
The following figures show, respectively, the dimensions of single active arms, of single passive arms, and the
corresponding fixing bracket stand alone.
Fig 109 - Dimensions (mm)
