H-Class 39
Print Control (continued)
Menu Item Details
PRESENT DISTANCE
Sets the label stop position, where:
AUTO 0.00 (0 – 4.00 in.) Is the label output distance. The default setting (Auto)
configures this distance according to the positioning
requirements of the attached device (e.g., tear bar,
cutter, etc).
;
When set to 0.01 in., NONE is assumed; a zero (0)
positioning value will be used.
CUSTOM ADJUSTMENTS
These selections independently change the listed
parameters, allowing slight mechanical compensations
sometimes evident when multiple printers share label
formats or for special printer-specific formatting
adjustments, where:
DARKNESS
32 (1 – 64)
Controls the printhead strobe time (see HEAT, above)
to fine-tune the solid areas of an image.
CONTRAST
32 (1 – 64)
Fine-tunes the gray areas of an image.
ROW ADJUST
0000 DOTS (
–
XXX – XXXX)
Shifts the vertical start of print position upward or
downward to fine-tune ROW OFFSET; see Appendix B.
;
If shifting in the negative direction, modify
PRESENT ADJUST (see below) by the same
amount.
COLUMN ADJUST
000 DOTS (
–
XXX – XXX)
Shifts both the horizontal start of print position and the
LABEL WIDTH termination point to the right to fine-
tune COLUMN OFFSET; see Appendix B.
PRESENT ADJUST
000 DOTS (
–
XXX – XXX)
Adjusts the label stopping position to fine-tune
PRESENT DISTANCE; see Appendix B.
