Datamax H-4212X User Manual

H-Class 61
Communications (continued)
Menu Item Details
SERIAL PORT C  Controls the settings for the optional Applicator
Interface Card’s COM C (J4) port, where the settings
are the same as those given for the SERIAL PORT A.
; The maximum baud is 38.4K BPS.
SERIAL PORT D  Controls the settings for the optional Applicator
Interface Card’s COM D (J3) port, where the settings
are the same as those given for the SERIAL PORT A.
; The maximum baud is 38.4K BPS.
PARALLEL PORT A 
Controls the communications settings for Parallel Port
A, where:
PORT DIRECTION Allows printer data to be returned to the host, where:
UNI-DIRECTIONAL Returns no data (one-way communication).
BI-DIRECTIONAL Returns data (compliant back-channel operation); see
Section 2.2.2 for cable requirements.
NIC ADAPTER 
Controls the communications settings for the network
interface, where:
QUICK SETUP
Selects between wired and WiFi operation, where:
WIRED DHCP
Returns the NIC to defaults then sets Discovery to
“Enable” and Wireless to “Disable.”
WLAN UNSECURED
Returns the NIC to defaults then sets Discovery to
“Enable,” SSID to “Any,” and WLAN Network Type to
“Infrastructure”
WLAN DEFAULTS
Allows the DMXrfNETII parameters to be restored to
the default settings, where:
YES
Restores the WiFi defaults and initiates infrastructure
mode with an SSID of “Any.” All existing access point
associations will be deleted then established with the
closest available access point. (Useful when moving
the printer to a geographically distant location.)
NO
Exits the menu item without changing the current
settings.
