Datamax H-4212X User Manual

H-Class 79
Standard Calibration (continued)
Step Action Displayed Message Comment
E
Proceed according to the
media type:
• Die-Cut – Remove a
label or two from the
liner then install the
media. Position the
Media Sensor under the
liner area and press ESC.
• Notched (or Reflective) –
Install media. Position
the Media Sensor under
a notch (or black mark)
and press ESC.
• Continuous – Press ESC
then proceed to Step F.
For die-cut media:
SCAN BACKING
PRESS ESC KEY
yyy
- Or, for reflective media:
SCAN MARK
PRESS ESC KEY
yyy
- Or, for continuous
media:
REMOVE LABEL STOCK
PRESS ESC KEY
yyy
This sets the gap (or
mark) value, where ‘yyy’
represents the current
sensor reading.
;
(1) See Section 3.2 for
sensor adjustment
instructions.
(2) Do not position a
perforation over the
sensor when taking
the sample.
(3) For small notches or
reflective marks,
ensure that the labels
exit straight from the
printer.
(4) Unless otherwise
noted, do not move
the Media Sensor
after this step.
F
Proceed according to the
media type:
• All media except
Continuous – Position
label material (and liner,
if any) over the sensor
then press the ESC Key.
• Continuous – Install
media. Position the
Media Sensor under the
stock and press ESC.
SCAN PAPER
PRESS ESC KEY
yyy
This sets the paper
value, where ‘yyy’
represents the current
sensor reading.
;
(1) If using preprinted
media, ensure that
the area placed over
the sensor is free of
text, graphics, or
borders.
(2) See Section 3.2 for
sensor adjustment
instructions.
