Datamax M-Class Mark II M-4206 User Manual

M-4206 59
Barcodes
Bar Code fonts have alpha names (left column in the table below). Uppercase alpha names will print barcodes with human-readable
interpretations. Lowercase alpha names will print barcodes only. The table is followed by visual samples.
Bar Code
ID
Type Length Check-
sum
Valid ASCII Characters,
decimal value
representation
A / a Code 3 of 9 Varies No 32, 36, 37, 42, 43, 45-57, 65-
90
B / b UPC-A 11 Yes 48-57 Numeric only
Option V used in the 6th &
7th position
C / c UPC-E 6 Yes 48-57 Numeric only
D / d Interleaved 2 of 5 (I
2 of 5)
Varies No 48-57 Numeric only
E / e Code 128 Varies M-103 32-127
F / f EAN-13 12 Yes 48-57 Numeric only.
Option V used in the 7th &
8th position
G / g EAN-8 7 Yes 48-57 Numeric only
H / h Health Industry Bar
Code
Varies M-43 32, 36-39, 42, 43, 45-57, 65-
90
I / i Codabar Varies No 36, 43, 45-58, 65-68
J / j I 2 of 5 with modulo
10 checksum
Varies M-10 48-57 Numeric only
K / k Plessey Up to 14 M-10 48-57 Numeric only. Option +
is Last Character for Second
M-11 checksum
L / l I 2 of 5 with modulo
10 checksum &
bearer bars
13 M-10 48-57 Numeric only
M / m 2 digit UPC
addendum
2 Yes 48-57 Numeric only
N / n 5 digit UPC
addendum
5 Yes 48-57 Numeric only
O / o Code 93 Varies No 35-38, 42-58, 65-90, 97-122
p Postnet Varies Yes 48-57 Numeric only
Q / q UCC/EAN Code 128 19 Yes 48-57 Numeric only
R / r UCC/EAN Code 128
K-Mart NON EDI
bar code
18 Yes 48-57 Numeric only
S / s UCC/EAN Code 128
Random Weight
34 + Yes 48-57 Numeric only
T / t Telepen Varies Yes Alphanumeric
U UPS MaxiCode 84 Yes Alphanumeric

Datamax M-Class Mark II M-4206 Specifications

General

Print Resolution	203 dpi
Print Method	Thermal Transfer and Direct Thermal
Max Print Width	4.25 inches
Max Print Speed	6 ips
Memory	8 MB Flash
Interfaces	Serial, Parallel, USB
Media Sensor	Reflective and Transmissive
Media Types	Labels, Tags
Label Roll Diameter	8 inches
Label Thickness	0.0025 to 0.01 inches
Maximum Print Length	99 inches
