SET DEFAULTS * Depending upon the RFID MODULE, selecting YES will return these settings:
If MODE = HF, then:
RFID POSITION = 1.10
HF SETTINGS:TAG TYPE = ISO 15693
RETRY ATTEMPTS = 3
--------------------------------------------------------------------------------------------
----
If MODE = UHF, then:
RFID POSITION = 1.10
UHF SETTINGS:TAG TYPE = GEN 2; TAG DATA SIZE = 96-BIT
RETRY ATTEMPTS = 3
GPIO PORT
Controls the optional Applicator Interface Card’s GPIO function, where:
GPIO DEVICE Sets the option to work with a specific device type, where:
DISABLED Disables the option.
APPLICATOR
Enables the following GPIO parameters for label applicator functions:
• De-asserts Data Ready (DRDY) when the last label starts printing to indicate
completion;
• FEED allowed at any time; and,
• Does not de-assert DRDY upon PAUSE.
BARCODE
VERIFIER
Enables the GPIO Port to work with a bar code verifier.
START OF PRINT Selects the type of input signal required to initiate Start of Print (SOP), where:
LOW PULSE Triggers printing with a low pulse.
HIGH PULSE Triggers printing with a high pulse.
ACTIVE LOW Triggers printing with a low signal.
ACTIVE HIGH Triggers printing with a high signal.
EDGE Triggers printing with a signal edge transition.
END OF PRINT Sets the type of output signal generated to indicate End of Print (EOP), where:
LOW PULSE Outputs a low pulse upon completion.
HIGH PULSE Outputs a high pulse upon completion.
ACTIVE LOW Outputs a logic low upon completion.
ACTIVE HIGH Outputs a logic high upon completion.
SLEW ENABLE Selects the type of input signal required to initiate label slew, where:
STANDARD Triggers slew with a low signal.
LOW PULSE Triggers slew with a low pulse.
HIGH PULSE Triggers slew with a high pulse.
ACTIVE LOW Triggers slew with a low signal.
ACTIVE HIGH Triggers slew with a high signal.
