S-Class 13
“Standard Media Sensor” using Roll Stock –
Mount the roll of ticket stock on the Roll Hanger so that it
unwinds in the direction shown by the arrow in the drawing
below. (The TOF Marks must be wound inward on the roll; see
Section 6 for ticket stock specifications).
Ensure that the Printhead Latch is in the ‘Locked’ position.
Roll Hanger
Unlocked
Locked
To Next Page
