Datavideo HS-1600T User Manual

23
Chapter 3 Switcher OSD Menu
The switcher’s OSD menu allows the user to perform several configurations of video effects, such as
picture-in-picture, luma key and etc. The user can also configure the audio settings in the Audio menu.
In the setup menu, the user is allowed to set video output resolution, reset to factory default, and
selects the interface language.
3.1 Start
Main
Sub-Menu
Options or Values
Default Value
Start
Transition Type
MIX
WIPE
Mix
Transition Speed
1-200 frames
60 frames; the duration
in second depends on
the Program OUT
resolution.
WIPE Effect
1. Horizontal
2. Vertical
3. Center
1
WIPE Border Size
OFF
Small
Middle
Large
Small
WIPE Border Color
White
Yellow
Cyan
Green
Magenta
Red
Blue
Black
Red
BKG Color
White
Yellow
Cyan
Green
Magenta
Red
Blue
Black
White
Transition Type
The HS-1600T provides two types of transition effect, which are cross dissolve (MIX) and WIPE. The
default setting is MIX.
Transition Speed
The Transition Speed allows the user to set the MIX or WIPE effect duration, in frames. If the
Transition Speed is set to a value of 60 then the transition will take effect over a period of 1 second if
the progressive video is chosen and 2 seconds if the interlaced video is chosen. When the AUTO
button is pressed, the transition will take the current Transition Speed defined by the user.
