Datavideo HS-1600T User Manual

35
Main Options
Sub Options
Values
Values
SPECIAL FUNCTION
OSD TIMOUT
5-120 SEC
FRAME RATIO
80 / 90 / 0FF
4:3 MARK LINE
ON / OFF
CENTRAL MARK
ON / OFF
CINEMA ZONE MARK
ON / OFF
AUDIO CHANNEL L*
AUDIO CHANNEL R*
EXIT
FACTORY RESET
EXIT
* Selectable on PGM only; external HDMI and MV are allowed on 1 and 2 ONLY.
MAIN ADJUST
After pressing the MENU button on the monitor control panel, the first menu option highlighted is the
MAIN ADJUST option.
Press ENTER to access the MAIN ADJUST Menu and the Brightness option will be highlighted.
To adjust the Brightness, press Enter again. Use the Up / Down buttons to change the value and then
press Enter to store the new value and return to the main menu.
To configure other settings such as Contrast, Saturation, Sharpness, TINT and etc, use the Up / Down
buttons to select the desired option. Follow the above procedure to set the new value.
COLOR
Press ENTER to access the COLOR menu and the first option will be highlighted.
Press ENTER to select the first color option.
Use the Up / Down buttons to navigate the available color options listed as follows.
 7500
 9300
 6500
 USER COLOR
Information
The System Information displays Horizontal Frequency, Vertical Frequency, Resolution and the
Firmware Version (Ver.) of the monitor.
Once selected, the information below will be displayed.
 H. FREQUENCY: 33.7KHZ
 V. FREQUENCY: 60.0HZ
 RESOLUTION: 1920X1080I
 VER.: 0.11
