Datavideo HS-1600T User Manual

27
Main
Sub-Menu
Options or Values
Default Value
Bottom
0 – 100%
0
The PIP Crop sub-menu options are described below:
 Left – Adjusts the position of the left edge of the PIP window.
 Right – Adjusts the position of the right edge of the PIP window.
 Size – Adjusts the PIP image crop size.
 Top – Adjusts the position of the top edge of the PIP window.
 Bot – Adjusts the position of the bottom edge of the PIP window.
3.4 Lumakey
Keyer of the HS-1600T provides the user with the capability of luma keying.
Note: When PIP and Lumakey features are enabled at the same time, the lumakey source will be
the upper layer and the PIP source will be the lower layer. The layer order cannot be changed.
Main
Sub-Menu
Options or Values
Default Value
Lumakey
Lumakey Source
Black
Input 1
Input 2
Input 3
Input 4*
Background
Color Bar
Input 2
Mode
Black
White
Black
Cleanup Level
0 – 100
20
Transparency
0 – 64
64
Lumakey Source
Lumakey source is where you can select the image for luma keying. The available sources are listed as
follows:
 Black
 Input 1
 Input 2
 Input 3
 Input 4*
 Background
 Color Bar
Mode
There are two modes available on the Luma Keyer. Select Black if the image is on a black background
and white if the image is on a white background.
Cleanup Level
The Cleanup Level allows the user to fine tune the effect of the luma key. The default value is 20.
