MAINTENANCE NOTICE
NM-275 index 09 Page 33/50 September 2021
8.7 Other functions
8.7.1 Reset options - Factory settings
It is possible to revert to the factory settings using the following combination:
Simultaneously press the buttons and for 15 seconds minimum and less than 30 seconds, the unit will reset
and return to the factory settings.
- From 0 to 15 seconds, the RGB LED is purple.
- After 15 seconds, the RGB LED flashes purple, release the 2 buttons and the reset will happen.
8.7.2 Locking / Unlocking buttons
The 2 buttons can be locked / unlocked using the following combination:
Press 3 times the button in less than 2 seconds to lock / unlock the buttons on the module.
- When the button locking is activated, RGB Led is lit purple for 2 seconds.
- When the buttons are unlocked, the RGB LED flashes purple for 2 seconds
- If a button is pressed while the locking is active, warning code # 15 will appear.
8.7.3 Interlock function
By default, the Interlock function is disabled. It is therefore possible to activate several solenoid valves simultaneously.
It is possible through IO-Link to activate the Interlock function. Therefore, only one solenoid valve can be controlled at a
time.
