Definox Sorio - Diagnostic

MAINTENANCE NOTICE
NM-275 index 09 Page 34/50 September 2021
8.8 Diagnostic
8.8.1 Warnings
The table below identifies the warning code.
Status
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
Auto
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
Manual
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
Tolerance
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
Error
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Code #
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Example:
Warning Code #13
LED S M T
CODE #
Feedback / Warning Description
LED
0
1
Status OK
S
2
Automatic calibration mode
A
3
4
Manual calibration mode
M
5
Pigging mode
6
7
8
Tolerance mode
T
9
Warning tolerance zone reached
S T
10
Limit reached of the shock loading counter
A T
11
Position movement time limit reached
S A T
12
Distance travelled counter limit reached
M T
13
Number of cycles counter limit reached
S M T
14
Operating time counter limit reached
A M T
15
Buttons locked / unlocked
S A M T
