Switches & fuses
The main battery switches are located in the aft
cabin on the port side. The outer switch
controls the domestic battery and the inner
switch controls the engine starter battery.
As already described elsewhere, the toggle
switches on the instrument panel incorporate
thermal trips. The fuse protection is 10 AH.
Other fuses are fitted by the yard or fitted with
instruments by the supplier:
Heating:
Eberspacher D3LC boat heating system is
additionally fused by a fitted EFEN 35A fuse.
The fuse is fitted behind the instrument panel.
The electric cable upstream of the heating
system can also be protected by a 25amp plug-
in fuse.
Refrigerator:
A plug-in fuse is factory fitted in the control
section of the refrigerator compressor.
Stowe Instruments:
The Data-box (fitted under the forecastle bunk)
is factory fitted with an extra glass fuse.
Electric winches:
The electric winches are fused by a fitted
EFEN 200A strip fuse, which is fitted aft of the
battery stowage compartment, on the
transverse bulkhead.
Electric winch switches:
The electric switches for the winches are fused
in the control box with an extra miniature fuse
at the factory. You will find the control box in
the cockpit locker.
Hot water Boiler:
The control for the pilot light is fused using a
miniature fuse. A floating fuse is located behind
the instrument panel.
Electric anchor windlass:
The automatic circuit breaker for the windlass
can be fitted in a variety of places. It can be
mounted behind the locker below the chart
table, in the locker seat or in the fore cabin. A
miniature fuse is located in the relay box at the
same point
Main & secondary electrical distribution
blocks
1. Connector block in starboard saloon locker:
Connected to this are the bi-colour bow light,
forecabin interior lighting, and starboard side
interior lighting forward of the mast.
2. Mast Connector block: Saloon lighting
above table, masthead light, anchor light and
tri-colour light are connected to this block fitted
under the ABS cover at the top of the mast
stanchion.
3. Connector block in locker under galley sinks:
The refrigerator, water pump, electric bilge
pump and supply lead for port side interior
lighting are connected to this block.
Familiarise yourself with the position of the
various fuses. Always keep replacement
fuses of various types on board.
Dehler 35 cws
40
