Description Notes
Deload active The controller is de-loading.
Ana. fan ref. set [1-2] active The analogue fan reference setting 1 or 2 is active.
Power droop active The frequency-dependent power droop is active.
Q droop active The voltage-dependent Q droop is active.
Cos phi droop active The voltage-dependent PF droop is active.
Idle run activated Idle run is activated.
Idle run deactivated Idle run is deactivated.
Load Depend Start/Stop setting 2 activated
Gensets start and stop according to the current load and the settings selected in
setting 2.
Load Depend Start/Stop setting 2
deactivated
Load-dependent starts and stops according to settings selected in setting 2 are
stopped.
Events, Events AC
Description
Notes
Three phase system Three phase AC configuration.
Split L1L3 phase system Split L1L3-phase AC configuration.
Split L1L2 phase system Split L1L2-phase AC configuration.
Single phase system Single phase AC configuration.
60 Hz system True if the nominal frequency is higher than 55 Hz.
L1L2L3 phase rotation active The phase rotation is L1L2L3.
L1L3L2 phase rotation active The phase rotation is L1L3L2.
Events, Events Parameter set
Description
Notes
Parameter set [1-4] used The parameter set can be selected internally or with binary input.
BB Parameter set [1-2] used Nominal busbar settings 1 or 2.
BB Unom = Gen Unom used Busbar nominal voltage is equal to the generator nominal voltage.
Events, Events Engine
Description
Notes
Running Engine is running.
Emergency stop Emergency stop activated.
DG ready for auto start All is normal, no alarms.
Cranking Crank output activated.
Start activated Start sequence activated.
Cool down active Cool down sequence in progress.
Eng. heater in manual ctrl. Force/release block of engine heater (toggle function).
Alternative start activated Alternative start is a full AMF sequence test of the plant.
Application note 4189341276B EN Page 18 of 50
