Events, Events Breakers
Description Notes
MB closed Mains breaker closed.
MB opened Mains breaker opened.
GB closed Generator breaker closed.
GB opened Generator breaker opened.
GB synchronising Generator breaker synchronising.
MB synchronising Mains breaker synchronising.
GB direct in Generator breaker is being closed on a dead busbar.
GB black close request Generator breaker direct close on request to dead busbar.
MB synchronisation to DG activated Mains breaker synchronisation activated.
MB synchronisation to DG deactivated Mains breaker synchronisation deactivated.
GB synchronisation to mains activated Generator breaker synchronisation activated.
GB synchronisation to mains deactivated Generator breaker synchronisation deactivated.
Events, Events Plant
Description
Notes
Application [1-4] activated Activate the application from the controller.
Single DG selected Single DG application selection.
Multi mains selected Multi-mains application selection.
Genset group selected Genset group application selection.
Genset group plant selected Genset group plant application selection.
Test application selected with output cmd
enabled
Emulation with engine and breaker relay reaction.
Test application selected with output cmd
disabled
Emulation without engine and breaker relay reactions.
Events, Events Power management (option G5)
Description
Notes
DG in quarantine The diesel generator cannot be used.
Any mains protection alarm active At least one mains protection alarm is active.
Multi-start set 1 selected Selection of generator sets to be started upon blackout.
Multi-start set 2 selected Selection of generator sets to be started upon blackout.
Dynamic section equal static section Power management feature.
Update mode local selected Update of setting on local controller.
Update mode on all selected Update of setting on all controllers.
Absolute prio. used Fixed start priority.
Relative prio. used Start priority relative to running hour counters.
Fast start sequence from Auto start/stop via
Digital input 117 READY
See Fast start of engine in Option G5 Power management.
Fast start sequence from Mains via Power
management READY
See Fast start of engine in Option G5 Power management.
Application note 4189341276B EN Page 19 of 50
