Description Notes
Act. max. ventilation Activates max. ventilation.
Deact. max. ventilation Deactivates max. ventilation.
Act. Frequency droop regulation Activates frequency droop regulation.
Act. Voltage droop regulation Activates voltage droop regulation.
Shutdown override Activates shutdown override.
Mains Okay
This function can be used if an input has been configured to Mains Okay. When it
is set, the command Mains Okay is given. This command is sometimes called
External Mains Okay.
Access lock Activates access lock.
Alternative start Activates alternative start.
Activate ana. fan ref. set [1-2] Activates analogue fan reference parameters.
Activate Idle run Activates idle run.
Deactivate Idle run Deactivates idle run.
Mains P measurement for droop reference Activates the P measurement directly from a transducer.
Mains Q measurement for droop reference Activates the Q measurement directly from a transducer.
Mains U measurement for droop reference Activates the U measurement directly from a transducer.
Frequency offset measurement for droop Activates the frequency offset directly from a transducer.
Activate load depend start/stop setting 2 Activates setting 2 for load-dependent start/stop.
Deactivate load depend start/stop setting 2 Deactivates setting 2 for load-dependent start/stop.
Activate load depend start setting 2 Activates setting 2 for load-dependent start.
Deactivate load depend start setting 2 Deactivates setting 2 for load-dependent start.
Activate load depend stop setting 2 Activates setting 2 for load-dependent stop.
Deactivate load depend stop setting 2 Deactivates setting 2 for load-dependent stop.
Output, Command AC
Description
Notes
Select three phase system Sets the controller to work in a three-phase system.
Select split L1L3 phase system Sets the controller to work in a two-phase system (L1-L3).
Select split L1L2 phase system Sets the controller to work in a two-phase system (L1-L3).
Select single phase system Sets the controller to work in a single-phase system (L1).
Select L1L2L3 phase rotation Activates L1L2L3 as phase rotation direction.
Select L1L3L2 phase rotation Activates L1L3L2 as phase rotation direction.
Output, Command Parameter set
Description
Notes
Set parameter [1-4] Choose the parameter set for nominal settings.
Set BB parameter [1-2] Select the parameter set for busbar nominal settings.
Set BB Unom = Gen Unom Busbar nominal voltage is equal to the generator nominal voltage.
Application note 4189341276B EN Page 34 of 50
